| 제품 이름: | 효율적인 옹벽을위한 뜨거운 딥 아연 도금 용접 가비 벽 바구니 | 핵심 단어: | 용접 돌망태 바구니 |
|---|---|---|---|
| 유형: | 용접된 개비온 | 모양: | 직사각형 |
| 길이: | 0.3m-2m | 개비온 박스 폭: | 30cm |
| 아연 코팅: | 220-300g/m2 | 개비온 박스 높이: | 30cm, 50cm, 80cm, 100cm |
| 좌석 표면 색상: | 블랙/브라운/라이트 브라운 | 메쉬선 지름: | 4mm |
| 와이어 두께: | 4.0mm | 나사선 지름: | 3mm |
| 강조하다: | hot dip galvanized gabion baskets,welded gabion retaining wall,galvanized gabion wall baskets |
||
Hot Dip Galvanized Welded Gabion Wall Baskets For Efficient Retaining Wall
Hot-Dip Galvanized Welded Gabion Wall Baskets for Garden Retaining Structures
Crafted from welded steel mesh with hot-dip galvanized coating, these gabion baskets form durable retaining walls for sloped garden terraces and landscaped planting areas. The rigid rectangular units provide structural support for soil containment while creating tiered platforms for decorative vegetation. Designed to integrate with garden topography, the baskets allow drainage and root penetration through their open mesh design. Custom heights (40-120cm) and widths adapt to gradient changes in residential and commercial landscapes. The zinc-coated finish offers corrosion resistance while blending subtly with organic materials. Used for stabilizing elevated flower beds, sculpted garden slopes, or as architectural planting ledges.
The welded gabion basket details:
A) Panel: high quality galvanized panel of 50*50 or 75*75 mesh size
B) Sprial wires: good quality for same wire diameter as panel
C) Stifferens :4-8 stifferens per gabion, to make sure the gabion is more strong
| Type of welded Gabion | Wire Gauge Diameter | Mesh Size | Gabion Size |
| Galvanized | 3-5mm | 50X50,75X75,50X100 | 2*1*1, 1*1*1,1*1*0.5,etc |
| PVC Coated | 3.0/3.8mm | 50X50,75X75,50X100 | 2*1*1, 1*1*1,2*1*0.5,etc |
| 95% Zinc + 5% Al | 3-5mm | 50X100,75X75,100X100 | 1*1*0.5,2*1*1,1*1*0.3etc |
The welded gabion basket connection details
1. U -clips
2. C-ring
3. Lacing wire connection
4. Hook connection
The sprial wires & hooks or stiffeners is most popular as it's more strong for usage
Welded gabion basket advantage:
1. Economic. Just fill the stone into the gabions and seal it.
2. Simple installation. No special technology needed.
3. Weather proof under natural destroy, corrosion resistant.
4. Sludge in the stones is good for plant growing. Mixed to form a integrity with thenatural environment.
5. Good permeation can prevent the damage by hydrostatic.
6. Less transport freight. It can be folded together for transport and further installation.
7. No collapse even under big scope of deforming.
